Chapter 4 Troubleshooting

This chapter explains how to handle printer problems that may occur. If a problem cannot be

corrected, contact your Kyocera Mita dealer. This chapter explains the following topics:

• General Guidelines

• Print Quality Problems

• Error Messages

• Clearing Paper Jams
