A.3 General Description of Options
A-8
A.3.2 PF-30A Paper Feeder
The PF-30A paper feeder has two paper cassettes allowing a large number of sheets of paper
to be fed continuously for printing. The paper cassette can hold up to approximately 500
sheets of ISO A3, ISO A4, ISO A5, JIS B4, JIS B5, ledger, letter, and legal size (80 g/m²)
paper. This feeder is attached at the bottom of the printer as shown below.
Caution
To prevent the printer from tipping over because of weight in the printer and the upper
paper drawers, the CA-31B caster kit must be installed at the bottom-most paper
feeder, when an optional paper feeder or duplex unit is installed with the printer.
For detailed information on installing the paper feeder, see the manual supplied with the
paper feeder.
Figure A-9
