Printer Specification
C-3
Output tray capacities Face-down tray 500 sheets (80 g/m²)
Face-up tray 150 sheets (80 g/m²)
Operating environ-
ment
Temperature 10 to 32.5 °C (50 to 90.5 °F)
Relative humidity 15 to 80 %
Optimum condi-
tions
23 °C (73 °F), 60 % (relative humidity)
Altitude 2,000 m (6,500 feet) maximum
Illumination 1,500 lux or less
Power supply U.S.A. and Canada 120 V, 60 Hz, 11.5 A max
Europe, Asia, and
other countries
220 to 240 V, 50 or 60 Hz, 5.8 A max. at 230 V
Allowable voltage
fluctuations
± 10 % maximum
Allowable fre-
quency fluctuations
± 2 % maximum
Power con-
sumption
U.S.A
and
Canada
Maximum 1,296 W
Normal operation 833 W
Standby 193 W
Sleeping 22 W
Europe,
Asia, and
other
countries
Maximum 1,318 W
Normal operation 803 W
Standby 196 W
Sleeping 26 W
Noise
†
Printing LpA = 53 dB (A)
Standby LpA = 39 dB (A)
Sleeping Unmesurably low
Dimensions Printer
590 (23-1/4) wide
× 422 (16-5/8) high × 585 mm (23-5/16
inches) deep
Paper feeder
560 (22-1/16) wide
×251 (9-7/8) high × 566 mm (22-5/16
inches) deep
Weight Printer 76.3 kg (168-3/16 lb)
Paper feeder 19.1 kg (42-1/8 lb)
Duplexer 22.1 kg (48-3/4 lb)
† In accordance with ISO 7779 (Bystander Position, sound pressure level at the front)
Item Specification
Table C-1 (Continued)
