Kyocera FS-C8500DN Service Manual

2KA
1-3-67
U240
Method: [Finisher Sol]
1. Select the item to be operated.
2. Press the OK key. The operation starts.
Method: [Mail Box]
1. Select the item to be operated.
2. Press the OK key. The operation starts.
Method: [Booklet]
1. Select the item to be operated.
2. Press the OK key. The operation starts.
Completion
Press the Back key with the operation stopped. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Solenoid
Feed In Sol Paper entry solenoid (PESOL)
Rear Down Sol 1 Trailing edge holder solenoid 1 (TEHSOL1)
Rear Down Sol 2 Trailing edge holder solenoid 2 (TEHSOL2)
Sub Path Sol Relief path solenoid (RPSOL)
Sub Tray R Sol Feedshift solenoid 1 (FSSOL1)
Sub Tray L Sol Feedshift solenoid 2 (FSSOL2)
Booklet Sol Centerfold feedshift solenoid (CFSSOL)
Paddle Sol Paddle solenoid (PDSOL)
Hold Down Sol Paper holder solenoid (PHSOL)
Eject Sol Pressure switching solenoid (PSWSOL)
Punch Sol Punch pattern solenoid (PPSOL)
Display Motor
Carry Roll Mailbox drive motor (MBDM) is turned on at paper conveying
Branch Roll Mailbox drive motor (MBDM) is turned on at feedshift operation
Display Motor
Conv Mot Centerfold main motor (CMM)
Balde Mot Blade motor (BLM)
Bundle UP Mot Centerfold paper conveying belt motor 1 (CPCBM1)
Bundle Down Mot Centerfold paper conveying belt motor 2 (CPCBM2)
Width Test(A3) Centerfold side registration motor 1/2 (CSRM1/2)
Width Test(LD) Centerfold side registration motor 1/2 (CSRM1/2)
Staple Mot Centerfold staple motor (CSTM)

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
