Kyocera FS-C8500DN Service Manual

2KA-2
1-3-86
U464
Setting: [Calib Tmg Prt]
1. Change the setting value using the Left/Right Select keys.
2. Press the OK key. The value is set.
Setting: [Calib Drv Time]
1. Change the setting value using the Left/Right Select keys.
2. Press the OK key. The value is set.
Setting: [Calib Prt Rate]
1. Change the setting value using the Left/Right Select keys.
2. Press the OK key. The value is set.
Setting: [Custom]
1. Select On or Off.
Initial setting: Off
2. Press the OK key. The setting is set.
Setting: [AC Calib]
1. Select the color of the replaced developing unit or drum unit.
2. Select [On] using the Left/Right Select keys.
If the machine is installed at high altitude, select [High Altitude].
3. Press the OK key.
4. Select [Execute].
5. Press the OK key. AC calibration is executed.
6. When normally completed, [Complete] is displayed.
When an error occurs, an error code is displayed.
7. Turn the main power switch off and on.
Maintenance
item No.
Description
Display Description Setting range Initial setting
Timing(Sec) Setting the drive standard time of contin-
uous print
300 to 3600 (s) 1800
Display Description Setting range Initial setting
Time(Sec) Setting the drive standard time 300 to 3000 (s) 600
Display Description Setting range Initial setting
Threshold Lv Setting the standard printing ratio 0 to 100 (%) 20
Display Description
Off Set to custom settings in setting the calibration cycle under the menu mode
On Set to standard settings in setting the calibration cycle under the menu mode
Display Description
Cyan Developing unit C or drum unit C
Magenta Developing unit M or drum unit M
Yellow Developing unit Y or drum unit Y
Black Developing unit K or drum unit K
High Altitude Overall setting for installation at high altitude

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
