Kyocera FS-C8500DN Service Manual

2KA
1-3-89
U465
Data reference for ID correction
Description
References the data related to ID correction.
Purpose
To check the corresponding data.
Method
1. Press the OK key.
2. Select the item to be reference.
3. Press the OK key. The screen for the selected item is displayed.
Displaying: [T Count]
1. The current value is displayed.
Displaying: [XYZ (C)/XYZ (M)/XYZ (Y)/XYZ (K)]
1. The current value is displayed.
Maintenance
item No.
Description
Display Description
T Count Developing bias control value after ID correction
XYZ (C) Data of grayscale variance for cyan
XYZ (M) Data of grayscale variance for magenta
XYZ (Y) Data of grayscale variance for yellow
XYZ (K) Data of grayscale variance for black
Laser Power Scaling factor to the value determined in light amount calibration
Bias Calib Sensor value for toner thick layer calibration
Display Description
Before (C) Developing bias control value for cyan before ID correction
Before (M) Developing bias control value for magenta before ID correction
Before (Y) Developing bias control value for yellow before ID correction
Before (K) Developing bias control value for black before ID correction
After (C) Developing bias control value for cyan after ID correction
After (M) Developing bias control value for magenta after ID correction
After (Y) Developing bias control value for yellow after ID correction
After (K) Developing bias control value for black after ID correction
Display Description
DATA1 Data of grayscale variance 1
DATA2 Data of grayscale variance 2
DATA3 Data of grayscale variance 3
DATA4 Data of grayscale variance 4
DATA5 Data of grayscale variance 5
DATA6 Data of grayscale variance 6
DATA7 Data of grayscale variance 7
DATA8 Data of grayscale variance 8

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
