Kyocera FS-C8500DN Service Manual

2KA
1-4-3
Section Jam code Conditions
Specified time
Color
B/W
System 00
Initial JAM
The power is turned on when a sensor in the conveying
system is on.
--
04
Cover open JAM
Cover is open during paper conveying. - -
05
Secondary paper feed
does not start
Secondary paper feed does not start within specified time
of arrival of paper at the registration section.
40 s 40s
09
Sequence error JAM
Sequence error is occurred between the machine and
3000-sheet paper feeder.
--
Paper
feed sec-
tion
10
No paper feed from
cassette 1
Feed switch 1 (FSW1) does not turn on within the specified
time of paper feed clutch 1 (PFCL1) turning on and cannot
be detected at the same timing even after retry.
1028 ms 935 ms
11
No paper feed from
cassette 2
Feed switch 2 (FSW2) does not turn on within the specified
time of paper feed clutch 2 (PFCL2) turning on and cannot
be detected at the same timing even after retry.
1080 ms 982 ms
12
No paper feed from
optional cassette 3
Feed switch 3 (FSW3) does not turn on within the specified
time of PF paper feed clutch 1 (PFPFCL1) turning on and
cannot be detected at the same timing even after retry
(paper feed from paper feeder).
2112 ms 1920 ms
Feed switch 3 (FSW3) does not turn on within the specified
time of PF paper feed clutch 1 (PFPFCL1) turning on
(paper feed from 3000-sheet paper feeder).
620 ms 620 ms
13
No paper feed from
optional cassette 4
The PF feed switch (PFFSW) does not turn on within the
specified time of PF paper feed clutch 2 (PFPFCL2) turning
on and cannot be detected at the same timing even after
retry (paper feed from paper feeder).
2112 ms 1920 ms
14
No paper feed from MP
tray
The MP paper feed switch (MPPFSW) does not turn on
within the specified time of the MP paper feed clutch
(MPPFCL) turning on and cannot be detected at the same
timing even after retry.
924 ms 840 ms
15
Misfeed in paper feeder
horizontal paper con-
veying section 1
Paper path sensor 3 (PPS3) does not turn on within speci-
fied time of PF paper feed clutch 2 (PFCL2) turning on
(paper feed from 3000-sheet paper feeder).
360 ms 360 ms
16
Misfeed in paper feeder
horizontal paper con-
veying section 2
Paper path sensor 2 (PPS2) does not turn on within speci-
fied time of the paper path sensor 3 (PPS3) turning on
(paper feed from 3000-sheet paper feeder).
380 ms 380 ms
17
Misfeed in paper feeder
horizontal paper con-
veying section 3
Paper path sensor 1 (PPS1) does not turn on within speci-
fied time of the paper path sensor 2 (PPS2) turning on
(paper feed from 3000-sheet paper feeder).
250 ms 250 ms

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
