Kyocera FS-C8500DN Service Manual

2KA
1-4-4
Paper
feed sec-
tion
18
Misfeed in vertical
paper conveying sec-
tion
The registration switch (RSW) does not turn on within spec-
ified time of feed switch 1 (FSW1) turning on.
844 ms 767 ms
Feed switch 1 (FSW1) does not turn on within specified
time of feed switch 2 (FSW2) turning on.
588 ms 535 ms
Feed switch 2 (FSW2) does not turn on within specified
time of feed switch 3 (FSW3) turning on.
1280 ms 1164 ms
Feed switch 1 (FSW1) does not turn off within specified
time of feed switch 2 (FSW2) turning off.
1224 ms 1113 ms
Feed switch 2 (FSW2) does not turn off within specified
time of feed switch 3 (FSW3) turning off.
720 ms 655 ms
Feed switch 1 (FSW1) does not turn off within specified
time of feed switch 2 (FSW2) turning on.
588 ms 535 ms
Feed switch 2 (FSW2) does not turn off within specified
time of feed switch 3 (FSW3) turning on.
1280 ms 1164 ms
19
Misfeed in paper feeder
paper conveying sec-
tion
Feed switch 3 (FSW3) does not turn on within specified
time of PF feed switch (PFFSW) turning on.
680 ms 618 ms
21
Multiple sheets in MP
tray paper feed section
The MP paper feed switch (MPPFSW) does not turn off
within specified time from start of paper feed.
924 ms 840 ms
The MP paper feed switch (MPPFSW) does not turn off
within specified time of its turning on.
Paper
length +
1000 ms
Paper
length +
909 ms
22
Multiple sheets in cas-
sette 1 paper feed sec-
tion
Feed switch 1 (FSW1) does not turn off within specified
time from start of paper feed.
1028 ms 935 ms
When paper feed from cassette 1, feed switch 1 (FSW1)
does not turn off within specified time of its turning on.
(Paper length: under 300 mm)
Paper
length +
1000 ms
Paper
length +
909 ms
When paper feed from cassette 1, feed switch 1 (FSW1)
does not turn off within specified time of its turning on.
(Paper length: more than 300 mm)
Paper
length +
1080 ms
Paper
length +
982 ms
23
Multiple sheets in cas-
sette 2 paper feed sec-
tion
Feed switch 2 (FSW2) does not turn off within specified
time from start of paper feed.
1080 ms 982 ms
When paper feed from cassette 2, feed switch 1 (FSW2)
does not turn off within specified time of its turning on.
(Paper length: under 373 mm)
Paper
length +
1000 ms
Paper
length +
909 ms
When paper feed from cassette 2, feed switch 1 (FSW2)
does not turn off within specified time of its turning on.
(Paper length: more than 373 mm)
Paper
length +
1080 ms
Paper
length +
982 ms
24
Multiple sheets in cas-
sette 3 paper feed sec-
tion
Feed switch 3 (FSW3) does not turn off within specified
time of its turning on (paper feed from paper feeder).
682 ms 620 ms
Feed switch 3 (FSW3) does not turn off within specified
time of its turning on (paper feed from 3000-sheet paper
feeder).
950
ms
950 ms
25
Multiple sheets in cas-
sette 4 paper feed sec-
tion
The PF feed switch 1 (PFFSW) does not turn off within
specified time of its turning on.
682 ms 620 ms
Section Jam code Conditions
Specified time
Color
B/W

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
