2KA
1-4-5
Paper
feed sec-
tion
26
Multiple sheets in MP
tray paper feed section
The MP paper conveying switch (MPPCSW) does not turn
on within specified time of MP paper feed switch
(MPPFSW) turning on.
2424 ms 2204 ms
The MP paper conveying switch (MPPCSW) does not turn
off within specified time of MP paper feed switch
(MPPFSW) turning off.
2504 ms 2276 ms
The registration switch (RSW) does not turn on within spec-
ified time of MP paper conveying switch (MPPCSW) turning
on.
1672 ms 1520 ms
The registration switch (RSW) does not turn off within spec-
ified time of MP paper feed switch (MPPFSW) turning off.
1272 ms 1156 ms
Paper
conveying
section
30
Misfeed in registration/
transfer section
The registration switch (RSW) does not turn off within spec-
ified time of feed switch 1 (FSW1) turning off.
956 ms 855 ms
31
Misfeed round the
transfer belt
The loop sensor (LS) does not turn on within specified time
of the registration clutch (RCL) turning on.
584 ms 531 ms
Fuser sec-
tion
40
Misfeed in fuser section
(MP tray)
Eject switch 1 (ESW1) does not turn on within specified
time of the loop sensor (LS) turning on.
696 ms 633 ms
41
Misfeed in fuser section
(cassette 1)
Eject switch 1 (ESW1) does not turn on within specified
time of the loop sensor (LS) turning on.
696 ms 633 ms
42
Misfeed in fuser section
(cassette 2)
Eject switch 1 (ESW1) does not turn on within specified
time of the loop sensor (LS) turning on.
696 ms 633 ms
43
Misfeed in fuser section
(cassette 3)
Eject switch 1 (ESW1) does not turn on within specified
time of the loop sensor (LS) turning on.
696 ms 633 ms
44
Misfeed in fuser section
(cassette 4)
Eject switch 1 (ESW1) does not turn on within specified
time of the loop sensor (LS) turning on.
696 ms 633 ms
45
Misfeed in fuser section
(3000-sheet paper
feeder)
Eject switch 1 (ESW1) does not turn on within specified
time of the loop sensor (LS) turning on.
696 ms 633 ms
46
Misfeed in fuser section
(duplex section)
Eject switch 1 (ESW1) does not turn on within specified
time of the loop sensor (LS) turning on.
696 ms 633 ms
Section Jam code Conditions
Specified time
Color
B/W

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
