Kyocera FS-C8500DN Service Manual

2KA
1-4-6
Eject
section
50
Misfeed in eject section
During top tray ejection, eject switch 1 (ESW1) does not
turn off within specified time of the registration switch
(RSW) turning off.
1432 ms 1302 ms
During finisher ejection, eject switch 1 (ESW1) does not
turn off within specified time of the registration switch
(RSW) turning off.
1432 ms 1302 ms
During switchback ejection, eject switch 1 (ESW1) does not
turn off within specified time of the registration switch
(RSW) turning off.
1432 ms 1302 ms
During duplex refeeding, eject switch 1 (ESW1) does not
turn off within specified time of the registration switch
(RSW) turning off.
1432 ms 1302 ms
Feedshift
section
52
Misfeed in feedshift
section
During finisher ejection, the feedshift switch (FSSW) does
not turn on within specified time of eject switch 1 (ESW1)
turning on.
348 ms 316 ms
During finisher ejection, the feedshift switch (FSSW) does
not turn off within specified time of eject switch 1 (ESW1)
turning off.
628 ms 571 ms
During duplex refeeding, the feedshift switch (FSSW) does
not turn on within specified time from start of paper switch-
back.
1041 ms 954 ms
During switchback ejection, the feedshift switch (FSSW)
does not turn on within specified time from start of paper
switchback.
1041 ms 954 ms
During switchback ejection, the feedshift switch (FSSW)
does not turn off within specified time from start of paper
switchback.
Paper
length +
641 ms
Paper
length +
590 ms
Duplex
section
60
Misfeed in duplex
paper conveying sec-
tion 1
The duplex switch (DUSW) does not turn on within speci-
fied time of the feedshift switch (FSSW) turning on.
2640 ms 2400 ms
During duplex refeeding, the duplex switch (DUSW) does
not turn off within specified time of the registration switch
(RSW) turning on.
Paper
length +
732 ms
Paper
length +
665 ms
61
Misfeed in duplex
paper conveying sec-
tion 2
During duplex refeeding, the registration switch (RSW)
does not turn on within specified time.
648 ms 589 ms
Finisher 80
Jam between the fin-
isher and machine
Paper ejection is not output from the machine to the docu-
ment finisher within specified time of the paper entry sensor
(PES) turning on.
15 s 15 s
The paper entry sensor (PES) turns on before the eject sig-
nal is output from the machine.
--
Section Jam code Conditions
Specified time
Color
B/W

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
