Page #161 background image
2KA
1-4-7
Finisher 81
Paper entry sensor non
arrival jam
(3000-sheet document finisher)
The paper entry sensor (PES) is not turned off even if a
specified time has elapsed after the machine eject signal
was received.
968 ms 880 ms
(3000-sheet document finisher)
The paper entry sensor (PES) is not turned on even if a
specified time has elapsed after the machine eject signal
was received.
968 ms 880 ms
(3000-sheet document finisher)
The paper entry sensor (PES) does not turn off within spec-
ified time of its turning on.
2128 ms 1935 ms
(Document finisher)
The paper entry sensor (PES) is not turned on even if a
specified time has elapsed after the machine eject signal
was received.
674 ms 612 ms
82
Jam in stapler
(3000-sheet document finisher)
The home position is not detected within the specified time
when driving the staple motor.
600 ms 600 ms
(Document finisher)
The staple home position sensor (STSPS) is not turned on
within the specified time when driving the staple motor
(STM).
--
83
Eject sensor stay jam
(3000-sheet document finisher)
Eject switch 1 (ESW1) is not turned off within specified time
of its turning on.
1404 ms 1404 ms
(Document finisher)
In the straight mode, the eject paper sensor (EPS) is not
turned off within specified time of its turning on.
--
(Document finisher)
In the bundle discharge mode or the staple mode, bundle
discharge operation does not turn off within specified time
since the operation starts.
902 ms 902 ms
84
Jam in eject section of
right sub tray (3000-
sheet document fin-
isher only)
Eject switch 2 (ESW2) is not turned off even if a specified
time has elapsed after the machine eject signal was
received.
1112 ms 1011 ms
Eject switch 2 (ESW2) is not turned on even if a specified
time has elapsed after the machine eject signal was
received.
1112 ms 1011 ms
Eject switch 2 (ESW2) is not turned off within specified time
of its turning on.
2128 ms 1935 ms
85
Jam in eject section of
left sub tray (3000-
sheet document fin-
isher only)
Eject switch 3 (ESW3) does not turn off within specified
time of paper entry sensor (PES) turning on.
1312 ms 1193 ms
Eject switch 3 (ESW3) does not turn on within specified
time of paper entry sensor (PES) turning on.
1312 ms 1193 ms
Eject switch 3 (ESW3) is not turned off within specified time
of its turning on.
2128 ms 1935 ms
Section Jam code Conditions
Specified time
Color
B/W
