Kyocera FS-C8500DN Service Manual

2KA
1-4-8
Finisher 87
Jam in eject section of
inner tray 2 (3000-
sheet document fin-
isher only)
Inner tray entry sensor 2 (ITPES2) does not turn on within
specified time of the paper entry sensor (PES) turning on.
2068 ms 1880 ms
Inner tray entry sensor 2 (ITPES2) does not turn off within
specified time of the paper entry sensor (PES) turning off.
1371 ms 1371 ms
88
Jam in eject section of
main tray (3000-sheet
document finisher only)
Eject switch 1 (ESW1) is not turned on within specified
time.
1324 ms 1324 ms
At the time of bundle up initial operation, paper conveying
belt home position sensor 1 (PCBHPS1) does not turn on.
--
At the time of bundle down initial operation, paper convey-
ing belt home position sensor 2 (PCBHPS2) does not turn
on.
--
At the time of side registration standby operation, side reg-
istration home position sensor 1 (SRHPS1) does not turn
off within specified time.
500 ms 500 ms
At the time of side registration standby operation, side reg-
istration home position sensor 2 (SRHPS2) does not turn
off within specified time.
500 ms 500 ms
89
Jam in center-folding
unit (3000-sheet docu-
ment finisher only)
The centerfold paper entry sensor (CPES) does not turn off
within specified time of centerfold paper conveying sensor
(CPCS) turning on.
3224 ms 2931 ms
The centerfold paper entry sensor (CPES) does not turn on
within specified time of centerfold paper conveying sensor
(CPCS) turning on.
3224 ms 2931 ms
The centerfold paper entry sensor (CPES) is not turned off
within specified time of its turning on.
2313 ms 2313 ms
The centerfold eject switch (CESW) is not turned on within
specified time.
4080 ms 4080 ms
The centerfold eject switch (CESW) is not turned off within
specified time of its turning on.
8200 ms 8200 ms
Centerfold side registration sensor 1 (CSRS1) is not turned
on within specified time.
600 ms 600 ms
Centerfold side registration sensor 2 (CSRS2) is not turned
on within specified time.
600 ms 600 ms
The home position is not detected within the specified time
after driving the centerfold staple motor (CSTM).
1000 ms 1000 ms
The centerfold paper conveying sensor (CPCS) is not
turned off within specified time.
1370 ms 1370 ms
The centerfold paper conveying sensor (CPCS) is not
turned on within specified time.
1370 ms 1370 ms
The centerfold paper conveying sensor (CPCS) is not
turned off within specified time of its turning on.
2313 ms 2313 ms
Section Jam code Conditions
Specified time
Color
B/W

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
