2KA
1-5-36
9. Pressing the lock lever and then remove the
power connector and the connector.
10. Replace the hard disk unit and refit all the
removed parts.
11. Perform maintenance mode U024 (HDD ini-
tializing) (see page 1-3-20).
12. Perform maintenance mode U917 (backup
data writing) (see page 1-3-99).
Figure 1-5-61
Lock lever
Lock lever
Hard disk
Power connector
Connector (black)
To Next Page
