Kyocera FS-C8500DN - Page 263

2KA
1-5-41
18. Raise the pin and slide it.
19. Remove the left cover 1 (paper conveying
unit).
20. Replace the left cover 1 (paper conveying
unit) and refit all the removed parts.
Figure 1-5-70
Pin
Pin
Left cover 1
(paper conveying unit)
