Kyocera FS-C8500DN Service Manual

2KA
1-3-3
High
voltage
U101 Setting the voltage for the primary transfer
Normal 116/90/120
Add Color 5/5/20/0/-5/-5/-15
Surround Correct On
U106 Setting the voltage for the secondary transfer
Light, Normal 1/(Full) Front 130/115/100/90
Light, Normal 1/(Full) Back 150/125/85/75
Light, Normal 1/(Full) Front B/W 150/115/110
Light, Normal 1/(Full) Back B/W 130/110/75
Normal 2-3/(Full) Front 150/125/110
Normal 2-3/(Full) Back 130/110/90
Normal 2-3/(Full) Front B/W 150/115/110
Normal 2-3/(Full) Back B/W 130/110/75
Heavy 1-3/(Half) Front 125/90/80
Heavy 1-3/(Half) Back 150/100/65
OHP 110/60
Bias 190/190/31/31/31
U107 Setting the transfer cleaning voltage
Belt Clean A (F) 93/93/93
Belt Clean A (H) 62/62/62
Belt Clean A B/W 120/120/120
Belt Clean B 150/120/150
U108 Setting separation shift bias
Set Output Value 85/60/52/60/8/26
85/60/52/60
Set Timing -150/0/40
U109 Checking the drum type -
U110 Checking the drum count -
U111 Checking the drum drive time -
U117 Checking the drum number -
U118 Displaying the drum history -
U119 Setting the drum -
U122 Checking the transfer belt unit number -
U123 Displaying the transfer belt unit history -
U127 Checking/clearing the transfer count -
U128 Setting transfer high-voltage timing -54/-54/10
Developing U131 Adjusting the toner sensor control voltage
Set Ope. Mode Automatic adjustment
Manual Adj. 116/116/116/116
Auto Adj. -
U132 Replenishing toner forcibly -
U135 Checking toner motor operation -
Section
Item
No.
Content of maintenance item
Initial
setting*
*: Factory initial setting, *1: The item initialized for executing U021

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
