Kyocera FS-C8500DN Service Manual

2KA-2
1-3-4
Developing U136 Setting toner near end detection 3/3
U139 Displaying the temperature and humidity outside the
machine
-
U140 Displaying developing bias
Dev Roll2 DC 93/93/93/93/93
Dev Roll1(Calb)DC 112/142/173/204/
112/142/173/204
Dev Roll2 AC 174/174/174/174/174
Dev Roll1DC 162/162/162/162/162
Roll1 DC Int 1/64/64/64/1
Dev Roll1AC 255/255/255/255/255
Dev Roll Freq 858/858/858/858/791
DEV Roll Duty 592/592/592/592/546
Dev Roll2 Duty 353/353/353/353/320
U147 Setting for toner applying operation
Operation Mode M1
Operation Value 50/5.0/60/M1/10/20
U148 Setting drum refresh mode -
U155 Displaying the toner sensor output -
U156 Setting the toner replenishment level
Supply Level 502/502/502/502/502
Empty Level 101/101/101/101/101
U157 Checking the developing drive time -
U158 Checking the developing count -
Fuser U161 Setting the fuser control temperature
Ready Temp. 165
*1
Stable (Drv) 170
*1
Stable (Stop) 170
*1
Full Prt 170
*1
Shift Prt Dup -5
*1
Roller Temp. 140
*1
U163 Resetting the fuser problem data -
U167 Checking/clearing the fuser count -
U199 Displaying fuser heater temperature -
Operation
panel and
support
equipment
U208 Setting the paper size for the paper feeder Letter (Inch)/A4 (Metric)
*1
U221 Setting the USB host lock function Off
*1
U223 Operation panel lock Unlock
*1
U234 Setting punch destination Inch (Inch)/Europe (Metric)
U237 Setting finisher stack quantity 0/0
*1
U240 Checking the operation of the finisher -
U241 Checking the operation of the switches of the finisher -
Section
Item
No.
Content of maintenance item
Initial
setting*
*: Factory initial setting, *1: The item initialized for executing U021

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
