Kyocera FS-C8500DN Service Manual

2KA
1-3-5
Operation
panel and
support
equipment
U246 Setting the finisher
3000 Finisher 0/0/0/0/0/0
*1
Booklet Fold 0/0/0/0/0/0/0/0
*1
U247 Setting the paper feed device -
Mode setting U250 Change the maintenance count pre-set -
U251 Checking/clearing the maintenance count -
U252 Setting the destination -
U253 Switching between double and single counts Double (A3/LD)
U260 Selecting the timing for copy counting Eject
*1
U265 Setting OEM purchaser code -
U278 Setting the delivery date -
U285 Setting service status page On
U325 Setting the paper interval On/1
U327 Setting the cassette heater control Off/Off
U328 Side ejection setting Off
*1
U332 Setting the size conversion factor 1.0
*1
U345 Setting the value for maintenance due indication 0
*1
processing
U464 Setting the ID correction operation
Permit On
Time Interval 480
Slp Period Calib 60
Permit Act(50pp) On
Permit(On/SlpOut) On
Permit(AP/NE) On
Calib Tmg Prt 1800
Calib Drv Time 600
Calib Prt Rate 20
Custom Off
AC Calib -
Target Value 500/500/500/10/
300/300/300/300
AC Calib Mag 3/3/3/3
Calib Prt Rate(H) 10
Calib Tmg Prt(H) 600
AC Calib Type Mode1
Prt Rate B/W 50
U465 Data reference for ID correction -
U467 Setting the color registration adjustment
Color Reg Adj On
T.B. Speed Adj On
Set Timing 10
Section
Item
No.
Content of maintenance item
Initial
setting*
*: Factory initial setting, *1: The item initialized for executing U021

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
