Kyocera FS-C8500DN Service Manual

2KA
1-3-6
processing
U473 Adjusting laser power output
Sensitivity -
LSU LD Power 16/16/16/16/16
Correction On
Density Adjust -
Emit Time/Dot All/0
U474 Checking LSU cleaning operation 1000/On
U486 Setting color/black and white operation mode Mode2
Other U901 Checking copy counts by paper feed locations -
U902 Checking/clearing finisher punch count -
U903 Checking/clearing the paper jam counts -
U904 Checking/clearing the call for service counts -
U905 Checking counts by optional devices -
U906 Resetting partial operation control -
U908 Checking the total counter value -
U910 Clearing the coverage data -
U911 Checking copy counts by paper sizes -
U917 Setting backup data reading/writing -
U920 Checking the copy counts -
U927 Clearing the all copy counts and machine life counts (one
time only)
-
U928 Checking machine life counts -
U930 Checking/clearing the charger roller count -
U964 Checking of log -
U969 Checking of toner area code -
U977 Data capture mode -
U984 Checking the developing unit number -
U985 Displaying the developing unit history -
U996 Setting the Self-diagnostic function mode -
Section
Item
No.
Content of maintenance item
Initial
setting*
*: Factory initial setting, *1: The item initialized for executing U021

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
