Kyocera FS-C8500DN Service Manual

4
9
K
K
G
G
C
D
割部を取り除く
7. 割部 (9) を切り取る。
カバーの組み立て
8. カバー後 (C) とカバー前 (D) に、カバーV(K) をビス M3 × 8 タップタイト P(G)1 本でそれぞれ取
り付ける。
Removing the divided part.
7. Cut out the divided part (9).
Reassembling the covers.
8. Install cover V (K) onto each of rear cover (C) and front cover (D) respectively with a M3 × 8 tap-
tight P screw (G).
Enlèvement de la pièce divisée.
7. Découper la pièce divisée (9).
Remontage des capots.
8. Installer le capot V (K) sur le capot arrière (C) et sur le capot avant (D) à l’aide d’une vis P
taraudée M3 × 8 chaque (G).
Extracción de la parte dividida.
7. Corte la parte dividida (9).
Reinstalación de las cubiertas.
8. Instale la cubierta V (K) en cada cubierta posterior (C) y cubierta frontal (D) respectivamente con
un tornillo de ajuste M3 × 8 (G).
Entfernen der Abtrennung.
7. Die Abtrennung (9) ausschneiden.
Anbringen der Abdeckungen.
8. Bringen Sie die Abdeckung V (K) auf jede hintere Abdeckung (C) bzw. vordere Abdeckung (D) mit
einer M3 × 8 Passstift-Verbundschraube (G) an.
Rimuovere la parte divisa.
7. Tagliare via la parte divisa (9).
Riassemblare i pannelli.
8. Installare il pannello V (K) su ognuno dei pannelli posteriore (C) e anteriore (D) rispettivamente
con viti con testa a croce P M4 × 8 (G).

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
