Kyocera FS-C8500DN Service Manual

2KA
1-3-28
U051
Adjusting the deflection in the paper
Description
Adjusts the deflection in the paper at the registration roller.
Purpose
Make the adjustment if the leading edge of the copy image is missing or varies randomly, or if the copy paper
is Z-folded.
Method
1. Press the OK key.
2. Select the item to be adjusted.
3. Press the OK key.
Adjustment
1. Select the item.
When [Bending Amt] is selected
Large size: 218 mm or more in width of paper.
Maintenance
item No.
Description
Display Description
Bending Amt Deflection adjustment
Bending Amt B/W Deflection adjustment in black and white mode
Display Description Setting
range
Initial
setting
Change in
value per step
MPT (L) Paper feed from MP tray
(when large size paper is used)
-30 to 20 -1 1 mm
MPT Half (L) Paper feed from MP tray
(when large size thick paper is used)
-30 to 20 7 1 mm
Cas (L) Paper feed from cassette
(when large size paper is used)
-30 to 20 1 1 mm
Cas Half (L) Paper feed from cassette
(when large size thick paper is used)
-30 to 20 13 1 mm
Dup (L) Duplex mode (second)
(when large size paper is used)
-30 to 20 -2 1 mm
Dup Half (L) Duplex mode (second)
(when large size thick paper is used)
-30 to 20 8 1 mm
MPT (S) Paper feed from MP tray
(when small size paper is used)
-30 to 20 -1 1 mm
MPT Half (S) Paper feed from MP tray
(when small size thick paper is used)
-30 to 20 -2 1 mm
Cas (S) Paper feed from cassette
(when small size paper is used)
-30 to 20 0 1 mm
Cas Half (S) Paper feed from cassette
(when small size thick paper is used)
-30 to 20 4 1 mm
Dup (S) Duplex mode (second)
(when small size paper is used)
-30 to 20 -2 1 mm
Dup Half (S) Duplex mode (second)
(when small size thick paper is used)
-30 to 20 -1 1 mm

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
