Kyocera FS-C8500DN Service Manual

2KA
1-3-29
U051 When [Bending Amt B/W] is selected
Large size: 218 mm or more in width of paper.
2. Change the setting value using the Left/Right Select keys.
The greater the value, the larger the deflection; the smaller the value, the smaller the deflection.
3. Press the OK key. The value is set.
Remark
When changing the setting value of [Large] each item is modified, equal to amount of the value which is
changed adds also the value of [Small] each item and is pulled.
Completion
Press the Back key. The indication for selecting a maintenance item No. appears.
Maintenance
item No.
Description
Display Description Setting
range
Initial
setting
Change in
value per step
MPT (L) B/W Paper feed from MP tray
(when large size paper is used)
-30 to 20 -1 1 mm
Cas (L) B/W Paper feed from cassette
(when large size paper is used)
-30 to 20 1 1 mm
MPT (S) B/W Paper feed from MP tray
(when small size paper is used)
-30 to 20 -1 1 mm
Cas (S) B/W Paper feed from cassette
(when small size paper is used)
-30 to 20 0 1 mm

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
