Kyocera FS-C8500DN Service Manual

2KA
1-3-31
U053
Setting the adjustment of the motor speed
Description
Performs fine adjustment of the speeds of the motors.
Purpose
Basically, the setting need not be changed.
Modify settings by interlock setting only if faulty images occur.
Method
1. Press the OK key.
2. Select the item to be adjusted.
3. Press the OK key.
Setting: [Set Motor1]
1. Select the item to be adjusted.
Setting: [Set Motor2]
1. Select the item to be adjusted.
Maintenance
item No.
Description
Display Description
Set Motor1 Adjustment of drum motor M, C, Y, K speeds
Set Motor2 Adjustment of developing motor K, developing motor MCY, transfer
motor, polygon motor, middle motor and registration motor speeds
Set Motor3 Adjustment of MP motor, eject motor, feedshift motor, fuser motor and
duplex motor speeds
Set Motor4 Drum motor K speed adjustment in black/white mode
Set Motor5 Adjustment of developing motor K, transfer motor, polygon motor,
middle motor and registration motor speeds in black/white mode
Set Motor6 Adjustment of MP motor, eject motor, feedshift motor, fuser motor and
duplex motor speeds in black/white mode
Display Description Setting range Initial setting
Drum C(Full) Drum motor C (DRM-C) full speed -500 to 500 9
Drum M(Full) Drum motor M (DRM-M) full speed -500 to 500 9
Drum Y(Full) Drum motor Y (DRM-Y) full speed -500 to 500 9
Drum K(Full) Drum motor K (DRM-K) full speed -500 to 500 9
Drum C(Half) Drum motor C (DRM-C) half speed -500 to 500 47
Drum M(Half) Drum motor M (DRM-M) half speed -500 to 500 47
Drum Y(Half) Drum motor Y (DRM-Y) half speed -500 to 500 47
Drum K(Half) Drum motor K (DRM-K) half speed -500 to 500 47
Display Description Setting range Initial setting
Dev K Developing motor K (DEVM-K) -500 to 500 0
Dev CMY Developing motor MCY (DEVM-MCY) -500 to 500 0
TC(Full) Transfer motor (TRM) full speed -500 to 500 0
TC(Half) Transfer motor (TRM) half speed -500 to 500 0
Polygon(Full) Polygon motor (PM) full speed -500 to 500 0
Mid Roller Middle motor (MM) -500 to 500 0
Regist Registration motor (RM) -500 to 500 0

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
