Kyocera FS-C8500DN Service Manual

2KA
1-3-59
U155
Displaying the toner sensor output
Description
Displays the toner sensor output value.
Purpose
To check the output value for each color when any image problems occur.
Method
1. Press the OK key.
2. Select the item to be set.
3. Press the OK key. The screen for the selected item is displayed.
Displaying: [Overflow]
1. The current value is displayed.
Displaying: [Toner Sensor]
1. The current value is displayed.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
Overflow Waste toner sensor
Toner Sensor Control voltage value and replenishment level of toner sensor each
color
Display Description
Waste Toner Waste toner sensor
Display Description
Input C Toner sensor C output value
Input M Toner sensor M output value
Input Y Toner sensor Y output value
Input K Toner sensor K output value
Target C Toner replenishment level for cyan
Target M Toner replenishment level for magenta
Target Y Toner replenishment level for yellow
Target K Toner replenishment level for black

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
