Kyocera FS-C8500DN Service Manual

2KA
1-3-63
U167
Checking/clearing the fuser count
Description
Displays and clears the fuser count for checking.
Purpose
To check or clear the fuser count after replacement of the fuser unit. Also to clear the counts after replacing
unit.
Method
1. Press the OK key. The fuser count is displayed.
Clearing
1. Select [Clear].
2. Press the OK key. The count is cleared.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
U199
Displaying fuser heater temperature
Description
Displays the detected fuser temperature.
Purpose
To check the fuser temperature.
Method
1. Press the OK key. The current setting is displayed.
Completion
Press the Back key. The screen for selecting a maintenance mode No. is displayed.
U208
Setting the paper size for the paper feeder
Description
Sets the size of paper used in 3000-sheet paper feeder.
Purpose
To change the setting when installing the 3000-sheet paper feeder or the size of paper used in the paper
feeder is changed.
Setting
1. Press the OK key.
2. Select the paper size (A4, B5 or Letter).
Initial setting: Letter (Inch specifications)
A4 (Metric specifications)
3. Press the OK key. The setting is set.
4. Turn the main power switch off and on.
Maintenance
item No.
Description
Display Description
Count Fuser count value
Display Description
Heat Edge
Heat roller edge temperature (
C)
Heat Center
Heat roller center temperature (
C)
Press
Press roller center temperature (
C)
