LACO PROTOCOL DESCRIPTIONS TITANTEST™
115
© 2018 LACO TECHNOLOGIES, INC. - TitanTest itra01en1-07 SB.fm - 1807
Write all elements: Pseudo array index 255 in first DATA byte and values in
following DATA bytes
Response from slave (in case data are sent): Array index or pseudo array
index in first DATA byte and values in following DATA bytes
All elements of an array have the same Min/Def/Max value.
Array parameters in commands table (see chapter 12.4): The number of ar-
ray elements is set in brackets behind the data type.
12.3 Status Word
Status word bit no. Meaning
Bit 0 Device state Bit 0
Bit 1 Device state Bit 1
Bit 2 Device state Bit 2
Bit 3 Device state Bit 3
Bit 4 ZERO
Bit 5 Still warning
Bit 6 Measure range 0
Bit 7 Measure range 1
Bit 8 Measure range 2
Bit 9 Setpoint exceeded
Bit 10 Warnpoint exceeded
Bit 11 not used
Bit 12 Paging
Bit 13 Device warning
Bit 14 Device error
Bit 15 Syntax/Command error
Value Bit 3..0 Device state
0 0000 INIT
1 0001 RUNUP
2 0010 STANDBY
3 0011 VENT
4 0100 EVACUATION
5 0101 MEASURE
6 0110 CALIBRATION
7 0111 DISPLAY CAL
8 1000 ERROR
9 1001 WAIT EVACUATION
10 1010 not used
11 1011 not used
12 1100 not used
13 1101 not used
