LACO PROTOCOL DESCRIPTIONS TITANTEST™
120
© 2018 LACO TECHNOLOGIES, INC. - TitanTest itra01en1-07 SB.fm - 1807
300 012C Device identification UINT8[2] R Device identification
Index 0, Manufacturer ID: 5 - Laco
Index 1, Device ID: 1
301 012D Device name CHAR[*] R Get device name as ASCII string, "Titan-
Test"
310 0136 SW-version MC68 UINT8[3] R Software-version MC68
Index 0: Main version
Index 1: Sub version
Index 2: Debug version
315 013B SW-version TMP controller CHAR[6] R SW version TMP controller (character
string from TMP controller)
317 013D TMP controller name CHAR[6] R TMP controller name (character string
from TMP controller)
320 0140 CRC-code MC68 UINT16 R Checksum MC68
321 0141 DIP switch MC68 UINT8 R DIP switch setting of the MC68:
Bit7: S2, switch 4
Bit6: S2, switch 3
Bit5: S2, switch 2
Bit4: S2, switch 1
Bit3..2: not used,always 0
Bit1: S1, switch 3
Bit0: S1, switch 2
385 0181 Setpoint [mbar*l/s] FLOAT[3] R/W Setpoint [mbar*l/s]
Index 0: Vacuum
Index 1: Sniff
Index 2: AutoTest
386 0182 Warning limit [%] UNIT8[3] R/W Warning limit [%]
Index 0: Vacuum
Index 1: Sniff
Index 2: AutoTest
390 0186 Test leak extern vacuum [mbar*l/s] FLOAT[3] R/W Test leak extern vacuum [mbar*l/s]
Index 0: Mass 2
Index 1: Mass 3
Index 2: Mass 4 Helium
392 0188 Test leak extern sniff [mbar*l/s] FLOAT[3] R/W Test leak extern sniff [mbar*l/s]
Index 0: Mass 2
Index 1: Mass 3
Index 2: Mass 4 Helium
394 018A Test leak intern [mbar*l/s] FLOAT R/W Test leak intern in mbar*l/s
401 0191 Operation mode UINT8 R/W Operation mode
0 = Vacuum
1 = Sniff
2 = Auto Test
Command Name Data type R/W Meaning
dez hex
