LACO PROTOCOL DESCRIPTIONS TITANTEST™
127
© 2018 LACO TECHNOLOGIES, INC. - TitanTest itra01en1-07 SB.fm - 1807
12.5 Enumerations**
Interface protocol (command 26)
Analog output configuration (command 222)
Analog output leak rate scale (log. only) (command 223)
State calibration (command 260)
Value Meaning
0 ASCII (RS232/RS485 only)
1 Diagnostics (RS232/RS485 only)
2 LD Protocol (both)
3LRC (RC only)
Value Meaning
0off
1Pressure p2
2Pressure p1
3 Leak rate mantissa
4Leak rate exponent
5Leak rate linear
6Leak rate logarithmic
Value Meaning
0 0,5 V / decade
11 V / decade
22 V / decade
3 2,5 V / decade
45 V / decade
5 10 V / decade
Value Meaning
0Inactive
1 Wait "Test leak connected"
2Pump down
3 Wait "Test leak signal stable"
4 Autotune
5Measure ULTRA
6Measure FINE
7Measure GROSS
8 Wait "Test leak closed" or "Background
stable"
9 Background ULTRA
10 Background FINE
** Feature not available in TITANTEST™ Maintenance model
