LACO PROTOCOL DESCRIPTIONS TITANTEST™
128
© 2018 LACO TECHNOLOGIES, INC. - TitanTest itra01en1-07 SB.fm - 1807
PLC input state (command 261)
PLC output state (command 262)
11 Background GROSS
12 Wait "Calibration result"
Value
Index Bit
Meaning
0x0001 Pin 6 Start / Stop
0x0002 Pin 7 Vent
0x0004 Pin 8 Zero
0x0008 Pin 9 Calibrate
0x0010 Pin 10 Para 2
0x0020 Pin 11 ---
0x0040 Pin 12 Fill complete
0x0080 Pin 13 ---
0x0100 Sniffer button
0x0200 -----
0x0400 -----
0x0800 -----
0x1000 -----
0x2000 -----
0x4000 -----
0x8000 -----
Value
Index Bit
Meaning
0x0001 Pin 15 Ready
0x0002 Pin 16 Measure mode
0x0004 Pin 17 Leak
0x0008 Pin 18 Error
0x0010 Pin 19 Calibrate Acknowledge
0x0020 Pin 20 Fill Helium
0x0040 Pin 21 Bypass valve
0x0080 Pin 22 No Leak
0x0100 Relay 1
0x0200 Relay 2
0x0400 -----
0x0800 -----
0x1000 -----
0x2000 -----
0x4000 -----
0x8000 -----
Value Meaning
