LACO Technologies TITAN Test - 14.2 LD Protocol specific**; 14.3 ASCII Protocol specific**

LACO PROTOCOL DESCRIPTIONS TITANTEST™
136
© 2018 LACO TECHNOLOGIES, INC. - TitanTest itra01en1-07 SB.fm - 1807
*CONFig:PARTIALFlow:MEASure Configuration of partial flow pump for measuring mode
(Fore_PUMP, Fore_AND_Partial_flow_PUMP)
627 R/W
*CONFig:PEVACgross pressure limit EVAC -> GROSS in mbar 540 R/W
*CONFig:PFINEultra pressure limit FINE -> ULTRA in mbar 543 R/W
*CONFig:PGROSSfine pressure limit GROSS -> FINE in mbar 541 R/W
*CONFig:PLCOUTLINK Configuration of Relais Output 1 (*CONFig:PLCOUTLINK:1) or 2
(*CONFig:PLCOUTLINK:2). The following settings are possible:
"OFF", "START", "STOP", "START_STOP", "READY", "SETPOINT",
"ON", "WARN_LIMIT", "BYPASS", "WARNING", "ERROR",
"WARNING_ERROR", "VENTED"
263 R/W
*CONFig:PROTection:
CONTamination
Gross leak protection (ON,OFF) 1855 R/W
*CONFig:PROTection:CONTLimit Gross leak protection limit 1854 R/W
*CONFig:PROTection:EVACtime Maximum evacuation time (0 means infinite) 555 R/W
*CONFig:PROTection:PMAX Maximum pressure in sniff 453 R/W
*CONFig:PROTection:PMIN Minimum pressure in sniff 452 R/W
*CONFig:RECorder:LINK1 Function at analog output channel 1
(OFF, P1, P2, MANT, EXP, LR_LIN, LR_LOG)
222 R/W
*CONFig:RECorder:LINK2 Function at analog output channel 2
(OFF, P1, P2, MANT, EXP, LR_LIN, LR_LOG)
222 R/W
*CONFig:RECorder:SCALE Analog leak rate scale 223 R/W
*CONFig:RECorder:UPPEREXP Analog output upper exponent 224 R/W
*CONFig:RS232 RS232 protocol (ASCII, BINARY, LD) 26 R/W
*CONFig:SETPoint Leak rate setpoint in selected unit 385 R/W
*CONFig:SUPPRession Offset suppression at start (OFF, INTERN, INLET) 548 R/W
*CONFig:TIMEAXIS Resolution of the time axis of Q(t) graph --- R/W
*CONFig:UNIT:LR Leak rate unit (mbar*l/s, Pa*m3/s, Torr*l/s, sccm, sccs, 
atm*cc/s, ppm, g/a, oz/yr)
431 R/W
*CONFig:UNIT:Pressure Pressure unit (mbar, Pa, atm, Torr) 430 R/W
*CONFig:VACRANGE Active vacuum ranges: GROSS, FINE and ULTRA as comma
seperated list
550 R/W
*CONFig:VOLume Volume 420 R/W
*CONFig:WARNLimit Warning limit 386 R/W
*CONFig:ZERO Zero mode (OFF, ON, AT_START) 410 R/W
*FACtor:RESistor Resistor factor 500G/15G 504 R/W
*FACtor:SNiff:M2 Calibration factor sniff mass 2 525 R/W
*FACtor:SNiff:M3 Calibration factor sniff mass 3 525 R/W
*FACtor:SNiff:M4 Calibration factor sniff mass 4 525 R/W
*FACtor:VACUUM_Fine:M2 Calibration factor vacuum FINE mass 2 525 R/W
*FACtor:VACUUM_Fine:M3 Calibration factor vacuum FINE mass 3 525 R/W
Command Meaning
Relates to LD cmd. no. Read/Set
