LACO ORIGINAL OPERATING INSTRUCTIONS TITANTEST™
78
© 2018 LACO TECHNOLOGIES, INC. - [TitanTest itna01en1-07 BA.fm] - 1807
8.6 Maintenance work further steps (All Series)
8.6.1 Turbo molecular pump
Maintenance work for devices with turbo molecular pump:
TITANTEST™ Wet Series
TITANTEST™ Dry Series
8.6.1.1 Replace the oil wick cartridge.
► Replace the oil wick cartridge every 2 years.
The turbo pump is filled with operating fluid upon the delivery of the Split-
Flow 80. The oil wick cartridge should be replaced every 2 years (in shorter
intervals accordingly in case of extreme loading or impure processes).
1. Switch on the mains plug.
2. Select "Start-up > Information > Vent TMP".
3. Wait for the message "TMP is vented. Please switch off leak detector".
4. Switch off the mains plug.
5. Pull out the mains plug.
6. In case an external backing pump is used, detach the KF 25 connection
to the external backing pump.
7. Carefully place the device on its back or left side (as seen from the front).
8. Use the special tool T10071 to unscrew the cover on the back.
Required material: Oil Wick SplitFlow 80 T10034
Danger of poisoning due to contact with harmful substances
The oil wick cartridge and parts of the pump may be contaminated with
toxic substances that are contained in the pumped media.
► Dispose of the oil wick cartridge as stipulated by local regulations.
► Prevent health hazards or environmental pollution from contamination
by means of suitable safety precautions.
► Decontaminate affected parts prior to executing maintenance work.
Material damage from changing the oil wick cartridge without prior
venting
► Before starting maintenance work, it must be ensured that the mass
spectrometer and the turbo pump are completely vented. Only when in
a vented state can the cover for the oil wick cartridge be removed.
► With the TITANTEST™, the mass spectrometer is vented via the software
(see step 2).
