Lauterbach TRACE32-ICD User Manual

PPC600 Family Debugger | 17
©
1989-2022 Lauterbach
On-chip Breakpoints
The following list gives an overview of the usage of the on-chip breakpoints by TRACE32-ICD:
•CPU family
• Instruction breakpoints: Number of on-chip breakpoints that can be used for program and spot
breakpoints
• Read/Write breakpoints: Number of on-chip breakpoints that can be used as read or write
breakpoints. Can be only set on 8 byte boundaries
• Data breakpoints: Number of on-chip data breakpoints that can be used to stop the program
when a specific data value is written to an address or when a specific data value is read from an
address.
NOTE: On-chip breakpoints can be cleared by the target application or by a target reset. If an on-chip
breakpoint is not hit, first check (with the peripheral view), if the on-chip breakpoint is set or not.
CPU Family Instruction
Breakpoints
Read/Write
Breakpoints
Data Value
Breakpoints
Notes
PPC603
RHPPC
MPC8240
MPC8245
MPC8255
MPC8260
MPC8265
MPC8266
1 single
address
— — Instruction
breakpoint is not
available if software
breakpoints are used
MGT5100
PPC7XX
MPC74XX
MPC86XX
1 single
address
1 single
address
— Instruction
breakpoint is not
available if software
breakpoints are used
MPC512X
MPC5200
MPC8247
MPC8248
MPC8270
MPC8275
MPC8280
MPC83XX
2 single
addresses
or
1 range
2 single
addresses
or
1 range
If software
breakpoints are
used, instruction
breakpoints are
reduced to one
single address
