Lauterbach TRACE32-ICD User Manual

PPC600 Family Debugger | 34
©
1989-2022 Lauterbach
SYStem.CONFIG.DriverStrength Configure driver strength of TCK pin
Default: HIGH.
Configures the driver strength of the TCK pin.
Available for debug cables with serial number C15040204231 and higher.
SYStem.CONFIG.QACK Control QACK pin
Controls the level and function of pin 2 (/QACK) of the debug connector. Default: TRISTATE.
Format: SYStem.CONFIG DriverStrength <signal> <LOW | MID | HIGH>
<signal>: TCK
Format: SYStem.CONFIG QACK TRISTATE | QREQ | LOW | HIGH
TRISTATE Pin is disabled (tristate).
QREQ Pin is driven to level of QREQ (pin 5).
LOW Pin is driven to GND permanently.
HIGH Pin is driven to JTAG_VREF permanently.
