PPC600 Family Debugger | 51
©
1989-2022 Lauterbach
SYStem.Option.WaitReset Set reset wait time
Set the time that the debugger will wait after releasing the reset pin, e.g. at SYStem.Up. If called without
parameter, the default reset wait time is used (10us).
If the reference is set to default, the wait time starts when the debugger releases reset. If the reference is set
to RESET or RSTOUT, the wait time starts when the debugger detects that reset is released on the
corresponding pin.
Use this command when SYStem.Up fails, and the message AREA shows the message “Target reset
detected during system.up sequence”. A wait time of several ms should be sufficient. If a wait time > 10ms is
required, the target might require a stronger RESET pull-up resistor.
Format: SYStem.Option.WaitReset [<time> [<reference>] ]
<time>: 1us…10s
<reference>: default
RESET
RSTOUT
RESET pin
hold time wait time
CPU State
RESET/BIST RESET DEBUG_HALT
