PPC600 Family Debugger | 60

1989-2022 Lauterbach

BMC.FREEZE Freeze counters while core halted

Enable this setting to prevent that actions of the debugger have influence on the performance counter. As

this feature software controlled (no on-chip feature), some events (especially clock cycle measurements)

may be counted inaccurate even if this setting is set ON.

Format: BMC.FREEZE [ON | OFF]
