LV5300/LV5350/LV7300QuickManual
Vector Display(no.1)
14
Variablescaledisplaysetting
・ Press(VECTORSCOPE)todisplaythevectorscope.
Set(VECTORSCALE)>(VARIABLESCALE)toON.
Set(upmenu)>(VECTORGAIN)>(GAINVARIABLE)toVARIABLE.
Ifyouneedmorethan2timesmagnification,changeF2(GAINMAG)toX5andF3(GUIDEDISPLAY)toON.
Thecenterpositioncanbe
movedwith(VPOS)/ (HPOS).
UseFD(FUNCTIONDIAL)orflywheelofmousetoenlarge/reducethevectordisplay.
PressFD(FUNCTIONDIAL)toreturntoX1.
VECT
F･2
Note:Ifisnot(VECTORSCALE),press(VECTORSCOPE)twice.
F･2
VECT
F･5
VARIABLESCALEOFF
F･7
F･3
F･1
F･2
F･3
F･D
F･D
VARIABLESCALEOFF
VARIABLESCALEON: x2 setting VARIABLESCALEON: Zoomout
VARIABLESCALEON: x5 setting
VARIABLESCALEON:x5,
ChangeV‐POS/H‐POSand
ShowG/Cy.
VPOS
HPOS
G
Cy
GUIDEDISPLAY表示
