LV5300/LV5350/LV7300QuickManual
CINELITE (% display)
Max3points(P1~P3) levelcheckispossible
＞ (CINELITE or CINELITE/HDR)＞ (CINELITEDISPLAY) ＞ %DISPLAYsetting
＞ (CINELITEorCINELITE/HDR)＞ (%DISPLAYSETUP)
・ (MEASURENUMBERS)： Measurementpointsettingtodisplay,P1,P1+P2,P1+P2+P3
・ (MEASUREPOSITION)： Selectthemeasurementpointtomovethecursor,use tomovecursor
・ (MEASURESIZE)：measurementsizechoose,1x1(1Pixel),3x3(3x3Pixelaveraging,9x9(9x9Pixelaveraging)
・ (UNITSELECT)： Brightnesslevelvaluedisplaysetting,Y%,RGB%,RGB255,CV,CV(DEC),HDR
(*HDR→WithoptionforLV5600‐SER23(HDR),HDR settingforONisavailable.)
・ (SELECTCH)：displaychannelswitch
CINELITEADVANCEFUNTION
＞ (CINELITE/HDR)＞ (CINELITEADVANCE)
＞ ON ＞ MeasurementpointssetonCineLite screen ＞
P1toP3andREFasvectorwaveformscreenandvideo
signalmarkerscanbedisplayedinconjunctionwiththe
waveformscreen.
