LV5300/LV5350/LV7300QuickManual
Phasedifferencemeasurement
Phasedifferencemeasurement Setting (Notincluding12G‐SDI)
＞ (SDIANALYSIS)＞ (EXTREFPHASE)
Asa The referencesignalforphasedifferencemeasurement,from (REFSELECT) tochooseEXT,SDIorEXT,
EXTREF Inputsignal,SDIisSDIAinputsignal.WhentheSystemsettingisSD/HD/3G‐A/3G‐B‐DL, ＞
(DISPLAY) ＞ (SELECTCH) ＞Choose
(TousetheEXTREFsignal,whenusingEXT,press)
(REFSELECT)‐EXT＞ Press (REFSETUSER)＞ Phasedifferencecanbezero
Returnphasedifferencetoinitialsetting,press (REFSETDEFAULT)
(0HTIMING) Setting
LEGACY :WhenanexternalsynchronizationsignalwithouttimingoffsetandSDIsignaloutputfromour
company‘ssignalgeneratorarereceived,setthephasedifferenceto0.
(Thisisthenormalsettingmode,suchasincaseofathirdpartyproductoraproductthatcannotsetSERIAL)
SERIAL :WhenthereceivedexternalsynchronizationsignalandtheSDIsignalhavethetimingdefinedbythesignalstandard,
setthephasedifferenceto0.
28
F･2
STATUS
F･2
F･1
F･6
F･1
F･2
F･3
F･4
2input when REFSELECT:SDI 2 input when REFSELECT:EXT
HD input(SDIA input) whenREFSELECT:EXT
AstheSDIAinputbecomesthereference,thephasedifferencemeasurement
valueisnotdisplayedontheupperleft.
EXTDisplaysthephasedifferenceofeachSDIinputtotheREFinput.
WhentheSystemsettingisSD/HD/3G‐A/3G‐B‐DL,measurethephase
differencewiththechannelsetwithSELECTCH
