LV5300/LV5350/LV7300QuickManual
Vector Display(no.1)
13
COLORBAR100%75%setting
・Press(VECTORSCOPE)todisplaythevectorscope.
Change(COLORSYSTEM)>(COLORBAR)to100%or75%
VECT
F･7
Note:Ifisnot(COLORSYSTEM),press,(VECTORSCOPE)twice.
F･7
VECT
F･2
VECTORSCALESetting
・ Press(VECTORSCOPE)todisplaythevectorscope.
Change(VECTORSCALE)>(VECTORSCALE)toAUTO/BT.601/BT.709/DCI/BT.2020.
WhenAUTOisselected,theColorimety settingofSDIsetting signal isused.
VECT
F･2
Note：Ifisnot(VECTORSCALE),press (VECTORSCOPE) twice.
F･2
VECT
F･2
Input75%COLORBAR SetCOLORBAR100%
(Offtarget)
SetCOLORBAR75%
InputBT.2020COLORBAR SetVECTORSCALEBT.709
(Off target)
SetVECTORSCALEBT.2020
