Leader LV5300A - Audio

AUDIO
(LV5300‐SER20, LV5350‐SER20, LV7300‐SER20)
SYS
F･1 F･2 F･3 F･4 F･5 F･6
F･7
INPUT
EXT
MULTI
WFM
VECT
PIC
CAP
AUDIO
STATUS
EYE
VPOS HPOS
F･D
MEM
RECALL
S‐CUT
LV5300/LV5350/LV7300QuickManual
24
Press (AUDIO)
AUDIO mapping setting
SetTargetinAu(AUDIO)>F7(MAPPING).
・INPUT： EMBAUDIO： MeasurementofembeddedaudioinputtoSDIINPUT
・CH Mode： Settingthenumberofmeasurementchannels（8ch）
・GROUP SELECT： Audiogroupsettings（G1/G2/G3/G4）
IftheINPUTsettingisSIMUL,youcanalsoselecttheinputchannel.
F･7
AUDIO
TARGET
AUDIOdisplaymodesetting
F7(upmenu)orAu(AUDIO)>F1(DISPLAYMODE)
・LISSAJOU: ViewtheLissajous.Anaudiometerisalsodisplayed.
・SURROUND:Surroundisdisplayedonthelefthalfandanaudiometerisdisplayedontherighthalf.
ThiscannotbeselectedduringSimulmode.
・STATUS: Showstatus.Anaudiometer
isalsodisplayed.
AUDIO
F･1
LISSAJOU
SURROUND
Note:IfF7isnot(MAPPING),pressAu(AUDIO)twice.
F･7
AUDIO
F･7
Note:IfF1isnot(DISPLAYMODE),pressAu(AUDIO)twice.。
F･1
AUDIO
