Leader LV5300A - (For UHDTV; HLG Color Bar)

SYS
F･1 F･2 F･3 F･4 F･5 F･6
F･7
INPUT
EXT
MULTI
WFM
VECT
PIC
CAP
AUDIO
STATUS
EYE
VPOS HPOS
F･D
MEM
RECALL
S‐CUT
LV5300/LV5350/LV7300QuickManual
Vector Display(no.3)
ForUHDTV/HLGcolorbar
３．VariablescaledisplayONandARIBCHECKMARCKERsetting
・ Press(upmenu).
・ SetF2(VECTORSCALE)>F5(VARIABLESCALE)toON.
・ SetF3(ARIBCHECKMARKER)toSTD‐B66.※COLORIMTRYmustbeBT2020.
F･2 F･5
VARIABLESCALEOFF
VARIABLESCALEON
SetSTD‐B66
１．InputtheUHDTVcolorbar(ARIBSTD‐B66).
２．Setthevectorscopeto75%.
・ PressVec (VECTORSCOPE)todisplaytheVectorscope.
・ SwitchF7(COLORSYSTEM)>F2(BAR)to75%.
VECT
F･7
Note:IfF2isnot(COLORSYSTEM),pressVE(VECTORSCOPE)twice.
F･2
VECT
F･2
F･7
F･3
４．VariablescaledisplayON
・ PressF7(upmenu).
・ SetF3(VECTORGAIN)>F1(GAINVARIABLE)to
VARIABLE.
・ TurningFD(FUNCTIONDIAL)scalesthevector.
・ PressFD(FUNCTIONDIAL)toreturntoX1.
ThecenterpositioncanbemovedwithVP(VPOS)/
HP(HPOS).
F･3
F･1
F･7
15
F･D
F･D
VPOS
HPOS
５.ForHLGcolorbar(ARIBSTD‐B72)
・InputARIBSTD‐B72pattern.
・SwitchtheF3(ARIBCHECKMARKER)instep3
abovetoSTD‐B72.
F･3
HLG(STD-B72)
UHDTV(STD-B66)
