Leader LV5300A - Waveform Display

SYS
F･1 F･2 F･3 F･4 F･5 F･6
F･7
INPUT
EXT
MULTI
WFM
VECT
PIC
CAP
AUDIO
STATUS
EYE
VPOS HPOS
F･D
MEM
RECALL
S‐CUT
11
Waveformdisplaycolorsetting(e.g.changetoMulti‐color)
・ Press(WAVEFORM)todisplaythewaveform.
(WFMINTEN/CONFIG)＞ (WFMCOLOR) ‐ SelectMULTI.
WFM
F･1
Note:IfF1isotherthan(WFMINTEN/CONFIG),press(WAVEFORM)keytwice
F･1
WFM
F･4
Waveformdisplaymatrixsetting (e.g.SetwaveformmodetoRGB)
・ (upmenu)＞ (COLORSYSTEM)＞ (COLORMATRIX)‐Select RGB.
InCOLORMATRIX,youcanselectYCbCr /GBR/RGB/COMPOSITE.
F･7
F･7
F･1
RGB display
WaveformdisplayON‐OFFsetting (e.g.ChangethewaveformtoRonly)
・ (upmenu)>(WFMINTEN/CONFIG)>(WFMMODE)‐ SetGandBtoOFF.
F･7
F･1
F･2
Rwaveformonly
Waveform display(No.1)
LV5300/LV5350/LV7300QuickManual
