LV5300/LV5350/LV7300QuickManual
PayloadID display
SRLive Metadata display
PAYLOAD display setting
PAYLOADcanbedisplayedbySta(STATUS)>F4(ANCPACKET)>F1(PACKETANALYSYE)>F2
(PAYLOADID).
※Note:IfyoupressSta(STATUS)andtheSTATUSscreenisnotdisplayed,orif(ANCPACKET)is
notdisplayedonF4,pressSta(STATUS)twice.
26
F･4
STATUS
F･2
STATUS
STATUS
F･4
F･1
3G‐SDIQuadLink: Link1
12G‐SDI: Subimage1
Colorimetry
BT.2020/BT.709
HDR
HLG/PQ
SRLive Metadata display setting
SRLiveMetadatacanbedisplayedbySta(STATUS)>F4(ANCPACKET)>F1(PACKET
ANALYSYE)>F4(V‐ANC)>F2(SMPTE)>F6(SRLive).
※Note:IfyoupressSta(STATUS)andtheSTATUSscreenisnotdisplayed,orif(ANCPACKET)is
notdisplayedonF4,pressSta(STATUS)twice.
F･4
STATUS
F･4
STATUS
STATUS
F･4
F･1
F･6
F･2
