Leaf Aptus-II Installation Guide

50 Chapter 6 – Hasselblad (500 Series)
Figure 1: Ports and sockets on the Leaf Aptus digital camera back
Figure 2: The Leaf Aptus digital camera back with a Hasselblad (500 series)
camera
FireWire port
[1]
Flash Sync socket
[2]
3
Camera-to-Back Sync socket
[3] Camera Control socket
[4]
3
4
1
2
