Attaching the Repeater 101
2. Connect the other end of the cable to the port on the computer.
Attaching the Repeater
1. Connect one of the FireWire cables from the computer to the single-
side connection of the repeater.
2. Connect the other FireWire cable from the digital camera back to one
of the ports on the double-side connection of the repeater.
Figure 2: Attaching the repeater
Tip: When you connect the FireWire cable after you start the Leaf Capture
application, the application automatically connects to the Leaf Aptus digital
camera back and recognizes the connected camera type.
Notes:
Attaching the repeater is optional.
If you want to extend the FireWire cable from 4.5m / 15 ft. to 9m / 30 ft., you
can purchase the Leaf Repeater and Cable Kit.
Note: To comply with the CE/FCC standard regulations, it is recommended to
use the FireWire cables that are supplied by Leaf.
