100 Chapter 11 – Working in Tethered Mode
Connecting the FireWire Cable
The FireWire cable (IEEE 1394A) links the computer to Leaf Aptus. The
cable carries both communication signals and electrical power. The cable
is a hot-plug cable that can be connected or disconnected without turning
the computer off or quitting the application.
1. Connect one end of the FireWire cable to the port at the bottom of
Leaf Aptus. Make sure that the FireWire cable connector is aligned to
the left of Leaf Aptus.
Figure 1: Connecting the FireWire cable to the Leaf Aptus digital camera
back
Important: The information in this chapter is relevant to all cameras in this
installation guide. Follow the specific installation procedures for the camera you
are using. It is important that you connect the FireWire cable correctly in order
not to cause unnecessary damage.
To avoid connection problems, use only the Leaf FireWire cable and repeater
supplied with Leaf Aptus.
