36 Chapter 4 – Mamiya 645 AF-D
2. Using the tweezers, push the focusing screen frame upwards until you
hear a click.
Attaching the Leaf Digital Camera Back to the Camera Body
1. Mount the Mamiya 645 AF-D camera body on a tripod.
2. Remove the protective cover plate from the digital camera back.
3. Align the groove on the digital camera back with the holder bracket
on the camera body, and then bring the top of the digital camera back
to the camera body.
4. Push the top of the camera back toward the camera body until it locks
into place.
Figure 6: Attaching the Leaf Aptus digital camera back to a Mamiya 645
camera body
Important:
Never apply pressure on other parts as this might affect focus.
Handle the focusing screen surfaces with care. They are delicate and easily
damaged.
Never touch the surface of the focusing screen. If there is dust on the screen, use
a blower or soft lens brush to remove it. If the focusing screen needs more
thorough cleaning, contact the nearest authorized Mamiya service center. Do
not attempt to clean the focusing screen yourself.
