Quick Installation Reference 81
Quick Installation Reference
1. Install the focusing screen mask into the viewfinder.
2. Mount the adaptor plate on the camera body. The procedure is the
same for both the Hasselblad and Mamiya adaptor plates.
3. Remove the protective cover from the Leaf Aptus digital camera back.
4. Attach the digital camera back to the adaptor plate.
5. Connect the Camera-to-Back Sync cable between the camera lens and
Leaf Aptus
. If you are working in tethered mode, go straight to step 7.
6. Install the compact flash card. The installation is complete.
Working in tethered mode:
7. Install the Leaf Capture application from the CD and start the
application.
8. Connect the FireWire cable between the computer and Leaf Aptus.
After you connect the cable, the application automatically connects to
the digital camera back. When the connection is established, the LED
indicator on the digital camera back turns from orange to green.
Note: You can use either a universal or 645AFD Leaf Aptus adaptor plate.
Notes:
If you want to work with an external flash or strobe, connect the Flash Sync cable
between the Leaf Aptus digital camera back and the flash or strobe unit.
To trigger the camera from the computer, connect the Camera Control cable
(not supplied with the camera back) between the camera body and Leaf Aptus.
