Leaf Aptus-II - Quick Installation Reference

Quick Installation Reference 41
Figure 1: The Leaf Aptus digital camera back ports and sockets
Figure 2: The Leaf Aptus digital camera back on a Hasselblad H1 camera body
FireWire port
[1]
Flash Sync socket
[2]
4
Camera-to-Back Sync socket
[3] Camera Control socket
[4]
1
2
3
4
