Using the Tripod U-adaptor
23
Connecting the Leaf Digital Magazine to a DC Power Supply
¾
Connect one end of the DC po
wer supply cable to the DC-IN port on
the Leaf digital magazine, and the other end to the pow
er outlet.
Figure
17: Connecting the Leaf Aptus digital camera back to a DC power
supply
Note:
When using the power supply
, you do not need to use batteries.
W
ARNING
:
Use only the supplied 12V DC power supply
.
72
74
