22 Chapter 2 – Using the Portable Hardware
To remove from the tripod:
1. Open the locking lever on the side of the Tripod U-adaptor (see 1 in
the illustration Mounting the camera and digital magazine attached on
to a tripod. on page 22).
2. Slide the safety lever (see 3 in the illustration Mounting the camera and
digital magazine attached on to a tripod. on page 22) to the left and
hold it.
3. Remove the camera from the Tripod U-adaptor.
Figure 16: Mounting the camera and digital magazine attached on to a
tripod.
[1]
[3]
[2]
Tripod U-adaptor
